Fig. 1 of Harley Mayenschein's Rolling Ball Display Clock Patent

This image of Figure 1 from US Patent 4,077,198, March 7, 1978, issued to Harley Mayenschein of Schaumburg, IL, was scanned by the author from a copy of the patent purchased from the US Patent and Trademark Office. US patent texts and images are in the public domain.

Note: Some web browsers do not display images with full fidelity. For best image quality, save these images to temporary files and view them with an offline image viewing program. Please note that even when saved to files the licensing terms and the disclaimers stated in the Legal Matters section of this document still apply to these images.

(1 photo, approximately 50.1 kilobytes total)

Mayenschein Patent, Fig. 1
